Test pin finger probe

The equipment complies with environmental test standards such as IEC 60884-1 2013, clause 9.2, IEC 60068-3-5, IEC 60068-3-6, IEC 60068-2-1 (Test A), IEC 60068-2-2 (Test B and Ca), IEC 60068-2-78 (Test Ca) and IEC 60068-2-30 (Test Db), and is used to evaluate the moisture resistance of electronic and electrical products, components and materials under different temperature and humidity conditions. In addition, the equipment can also be used for storage, transportation and operation adaptability tests in extreme temperature environments to ensure a comprehensive evaluation of the heat, cold and dryness resistance of the samples. Applicable test samples include power sockets, similar electrical appliances, plugs, sockets, switches and other hazardous electrical components, as well as electronic, electrical appliances, mobile phones, instruments and meters, automotive parts and other plastic products.

HC9934 creepage distance test card strictly complies with GB2099.1 Article 27, GB4706, GB7000, IEC60884-1, IEC60598, IEC335 and other international standards. It is specially designed to measure the distance between conductive parts of electrical appliances along the surface of insulating materials to ensure electrical safety.

HC9930 cover gauge Conforms to the standards: GB2099.1-2008 Section 24.17 and Figure 32, IEC60884-1 Figure 32,Suitable for checking the contour of covers or cover plates.

This testing probe is used to verify the protection against access to hazardous parts through top openings.It meets IEC, EN, UL and CSA Standards, including IEC 1010, IEC60065, EN61010-1, UL3101-1, and CSA 1010-1.

HT-I20，HT-I21 20N socket protection door probe strictly complies with GB2099.1 - 2008 and IEC884 - 1.2002 related standards. It is specially designed to check whether the live parts inside the socket protection door are touched to ensure the safety of electricity use.

HT-U06 strictly complies with UL1278 Figure 10.2 standard and is specially designed for protection testing of heating elements and heating components, ensuring the safety protection of flammable materials and people. It is your reliable testing partner.

HT-I29 flat probe strictly complies with international standards such as GB7000.9 Section 11.2 and IEC60598-2-20 Section 11.2. It is specially designed for light string detection to ensure that metal decorations are not electrified and ensure safety.

As a source manufacturer, our large baffle test finger HT-I02B strictly complies with GB/T16482-2008 Figure 2, IEC61032 Figure 2 and other international standards. It is used to test the basic protection against human contact with dangerous parts and the protection against finger contact, to ensure the safety of electrical products.

HT-U14 wedge probe strictly complies with international standards such as IEC 60950-1 Figure NAF.2 (S5366), NAF.3 (S5370) and BS 60950.1108/260/CD. It is specially designed for shredder protection testing and can accurately detect the accessibility of dangerous parts of shredders to ensure safe use.

HT-I12 large children test finger strictly complies with GB/T16842, IEC61032 and other international standards. It is specially designed to simulate the test of children aged 36 months to 14 years old coming into contact with dangerous parts. It can accurately detect the safety of electrical appliances and other products to ensure the safety of children.

This probe made of stainless steel and nylon, the sphere made of stainless steel, the baffle and handle made of nylon. The diameter of sphere is 50mm. Baffle diameter is 45mm. Baffle thickness is 4 mm. Handle diameter is 10mm. Handle length is 100mm. It has no force, but there is an M6 threaded hole at the end of the handle to connect the push-pull meter.

This test sphere probe confirms to IEC61032 figure 6 probe 2,IEC60529 of IP2. It is intended to verify the degree of protection of enclosures against ingress of solid foreign objects having a diameter of 12.5mm or greater. Customizable: used for enclosure protection test when open threaded hole of M6 at the end of the handle (connected with pull and push dynamometer) .The probe whose model number is with "T" is with force.
